Neutron HA – VRRP

The other way of handling high availability of the network service in OpenStack is based on the concept of VRRP. Unlike legacy and DVR-based routers, using VRRP has different requirements, as follows:

VRRP groups set up for virtual routers

Multiple network nodes

An additional dedicated network for high availability traffic

Designation of master and slave routers using virtual IPs

In a VRRP setup, a master router is configured with a virtual IP (VIP) that represents the next route hop acting as the default IP address for the routers pool. The network traffic load can also be spread amongst the available routers within the VRRP router group that can be configured based on the scheduler mechanism in the master router. In case of a failover event, a new master router will be elected and set as active. The VIP will be associated to the new master and immediately starts handling routing decisions.

It is important to note that the active/standby routers use the following essential terminologies to achieve a successful failover event:

Priority: An assigned router with the highest priority is marked as master. The priority range in a VRRP router group starts from 0 up to 255. The highest priority is 255.

Preemptive election mode: In case of a failed master router, the latter can be reassigned to resume its activity again if it is associated with the highest priority in the VRRP router group.

Non-preemptive election mode: An active router keeps operating as master although the presence of a backup router with highest priority was assigned during a normal operational network exercise. Switching to a new master occurs only if the currently active master fails.

Preemptive delay timer: The waiting time before starting an election for a new master.

Advertisement interval timer: The active router keeps informing the standby routers within the same VRRP router group about its health state. If backup routers do not receive an indication of state from the master once in a window of X times, a new election process will be started by sending VRRP advertisements and priority selection.
