Advanced Microsystems for Automotive Applications 2013 by Jan Fischer-Wolfarth & Gereon Meyer

Author:Jan Fischer-Wolfarth & Gereon Meyer
Language: eng
Format: epub
Publisher: Springer International Publishing, Heidelberg

From the INTEGREEN project “Stakeholders Aspiration” which are the high level requirements the formal “User Needs” will be extracted. After this FRAME offers a tool to generate the Functional View which are the functions or processes needed in order to satisfy the User Needs. Here are also considered the data stores and data exchange between the functions and processes.

The next step is the development of the physical architecture with the FRAME-tool. This shows where the processes are physically located.

The last step is the definition of the communication Layer. Here all data rates between the physical locations will be defined. This part is not included in the FRAME-tool (Fig 2).

Fig. 2View of ITS architecture sub-set creation [3]
