XamChat for Android

So if we compile and run the application, we can navigate to a fully implemented friends list screen, as shown in the following screenshot:

Composing messages

The next screen is a bit more complicated; we will need to create a ListView that uses multiple layout files for each row, depending on the type of the row. We'll also need to perform some layout tricks to place a view below the ListView and set up ListView to autoscroll.

For the next screen, let's begin by creating a new layout named Messages.axml in the layout folder of the Resources directory and then perform the following steps: 1. Drag a new ListView onto the layout. Set Id to @+id/messageList.

2. Check the box for Stack From Bottom and set Transcript Mode to alwaysScroll. This will set it up to display items from the bottom up.

3. Set the Weight value to 1 for ListView in the Layout tab under the LinearLayout section.

4. Drag a new RelativeLayout control onto the layout. Let Id be the default value, or remove it.

5. Drag a new Button control inside RelativeLayout. Set Id to @+id/

sendButton.

6. Check the box for Align Parent Right in the Layout tab.

7. Drag a new Plain Text control found in the Text Field section inside RelativeLayout to the left of the button. Set Id to @+id/messageText.

8. In the Layout tab, set To Left Of to @+id/sendButton, and set Width to match_parent.

9. Check the box for Center in Parent to fix the vertical centering..

[ 126 ]

Chapter 6

When completed, the XML file will be as follows:

<?xml version="1.0" encoding="utf-8"?>

<LinearLayout

xmlns:android="http://schemas.android.com/apk/res/android"

android:orientation="vertical"

android:layout_width="match_parent"

android:layout_height="match_parent">

<ListView

android:minWidth="25px"

android:minHeight="25px"

android:layout_width="fill_parent"

android:layout_height="wrap_content"

android:id="@+id/messageList"

android:layout_weight="1"

android:stackFromBottom="true"

android:transcriptMode="alwaysScroll" />

<RelativeLayout

android:minWidth="25px"

android:minHeight="25px"

android:layout_width="fill_parent"

android:layout_height="wrap_content">

<Button

android:text="Send"

android:layout_alignParentRight="true"

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:id="@+id/sendButton" />

<EditText

android:layout_width="match_parent"

android:layout_height="wrap_content"

android:layout_toLeftOf="@id/sendButton"

android:layout_centerInParent="true"

android:id="@+id/messageText" />

</RelativeLayout>

</LinearLayout>

Next, perform the following steps to make two more Android layouts: 1. Create a new layout named MyMessageListItem.axml in the layout folder of the Resources directory.

2. Open the layout and switch to the Source tab. Change the root XML element to a RelativeLayout.

3. Switch back to the Content tab and drag two TextView controls onto the layout.

[ 127 ]

XamChat for Android

4. In the Id field, enter @+id/myMessageText and @+id/myMessageDate respectively.

5. For both the views, set Margin to 3dp, and Width and Height to wrap_content.

6. For the first TextView, set Color under the Style tab to @android:color/

holo_blue_bright.

7. For the second TextView, check the Align Parent Right checkbox under the Layout tab.

8. Create a new layout named TheirMessageListItem.axml and repeat the process. Select a different color for the first TextView in the new layout.

Finally, we'll need to create a new activity for the screen. Create a new Android Activity named MessagesActivity.cs in the Activities directory. Begin with the standard code to set up an activity as follows:

[Activity(Label = "Messages")]

public class MessagesActivity : BaseActivity<MessageViewModel>

{

protected override void OnCreate(Bundle bundle)

{

base.OnCreate(bundle);

}

}

Next, let's implement a more complicated adapter than we implemented earlier, as follows:

class Adapter : BaseAdapter<Message>

{

readonly MessageViewModel messageViewModel =

ServiceContainer.Resolve<MessageViewModel>();

readonly ISettings settings =

ServiceContainer.Resolve<ISettings>();

readonly LayoutInflater inflater;

const int MyMessageType = 0, TheirMessageType = 1;

public Adapter (Context context)

{

inflater = (LayoutInflater)context.GetSystemService (

Context.LayoutInflaterService);

}

public override long GetItemId(int position)

{

return messageViewModel.Messages [position].Id;

}

[ 128 ]

Chapter 6

public override int Count

{

get { return messageViewModel.Messages == null ? 0

: messageViewModel.Messages.Length; }

}

public override Message this[int index]

{

get { return messageViewModel.Messages
