3.5 Generating the Test Harness State Machine

We transform the generated test inputs from the previous step into a state machine. We then inject this state machine as a composite state inside the test suite running state in the TH (cf. Fig. 2). As a result, the TH and the CUT communicate in a ping-pong fashion, CUT requests for the next test input and TH sends the next input until the end of the current test case and finally the test suit. Figure 4 shows parts of the test suite in the TH. A new test case starts once TH receives nextTest. Each state has a state entry action code, which is responsible for sending signals to the CUT (as well as collecting the sequences of sent signals for reporting purposes).

Fig. 4.Parts of the TH representing two test cases.
