MATLAB Mathematical Analysis by César Pérez López

MATLAB Mathematical Analysis by César Pérez López

Author:César Pérez López
Language: eng
Format: epub
Publisher: Apress, Berkeley, CA


>> [X,Y] = meshgrid(-2:0.05:2);

Z=X^2-Y.^2;

subplot(2,2,1)

surf(X,Y,Z)

subplot(2,2,2)

surf(X,Y,Z),view(-90,0)

subplot(2,2, 3 )

surf(X,Y,Z),view(60,30)

subplot(2,2,4)

surf(X,Y,Z), view (- 10, 30)

>> [X,Y]=meshgrid(-2:0.05:2);

Z=X.^2-Y.^2;

surf(X,Y,Z),shading interp,brighten(0.75),colormap(gray(5))

Exercise 4-1

Represent the surface defined by the equation:

>> [x,y]=meshgrid(0:0.05:2,-2:0.05:2);

>> z=y.^2.*(x-1).^2./(y.^2+(x-1).^2);

>> mesh(x,y,z),view([-23,30])

We could also have represented the surface in the following form:

>> ezsurf('y^2*(x-1)^2/(y^2+(x-1)^2)')
