Building iPhone and iPad Electronic Projects by Mike Westerfield

Author:Mike Westerfield
Language: eng
Format: epub, pdf
Tags: TECHNOLOGY & ENGINEERING / Sensors
ISBN: 9781449363451
Publisher: O’Reilly Media
Published: 2013-09-10T16:00:00+00:00

Figure 7-5. Full-size fin pattern for the ST-2

Figure 7-6. Full-size alternate fin pattern for the ST-2

The main part of the payload bay (see Figure 7-7) is also pretty standard. The only exception is the plug at the bottom of the payload bay. I could not find a nose plug for a BT-80 body tube, so I cut the top off of a nose cone and epoxied a ″ piece of balsa across the top to make my own. The finished plug was epoxied into the payload tube. I used epoxy because I wanted a very strong joint, but did not want to put too much of the nose cone in the payload tube—only about ″ of plastic was actually in the payload section.
