Advanced remote management – SSH tunnels and SSH redirections

SSH has two really powerful features; that is, SSH tunnels and SSH redirections. When an SSH connection is established, it can not only be used to send commands to the remote host and let us work on them as if they were our local system, but we can also create tunnels that interconnect our systems.

Let’s try to imagine a scenario that is common in many companies, where a virtual private network (VPN) is used to reach the internal network with all the services and servers, but with SSH instead of a regular VPN.

So, let’s put some context into this imaginary scenario.

We can use a host that gets external traffic for ssh redirected from our internet router to the ssh service in that system. So, in brief, our router gets connections on port 22 via TCP, and the connection is forwarded to our server. We will be naming this server bastion in this exercise.

With this in place, our common sense tells us that we will be able to reach that bastion host via SSH, even if we can use other tools or even ssh it to connect to other systems later.

Can we connect directly to other hosts in the internal network? The answer is yes, because, by default, SSH allows us to use TCP forwarding (sshd_config setting AllowTcpForwarding), which empowers us, as remote login users, to create port redirections and even a Socket Secure (SOCKS) proxy to be used for our connections.

For example, we can create a tunnel using that bastion host to reach our internal mail server via the Internet Message Access Protocol (IMAP) and Simple Mail Transfer Protocol (SMTP) protocols by just executing the following code:

ssh –L 10993:imap.example.com:993 –L 10025:smtp.example.com:25 user@bastionhost

This command will listen on local ports 10993 and 10025. All the connections that are performed there will be tunneled until bastionhost connects those to imap.example.com at port 993 and smtp.example.com at port 25. This allows our local system to configure our email account using those custom ports and use localhost as the server, and still be able to reach those services.

Tip

Ports under 1024 are considered privileged ports, and usually, only the root user can bind services to those ports. That’s why we use them for our redirection ports 10025 and 10093 so that those can be used by a regular user instead of requiring the root user to perform the ssh connection. Pay attention to ssh messages when you’re trying to bind to local ports in case those are in use, as the connections might fail. Furthermore, you can use additional -v, -vv, and -vvv modifiers to increase verbosity.

Additionally, from the target server’s point of view, the connections will appear as if they originated in the bastion server as this is the one effectively performing the connections.

When the list of open ports starts to grow, it is better to go back to what we explained at the beginning of this chapter: the ~/.ssh/config file can hold the host definition, along
