Mastering Data Visualization with Microsoft Visio Professional 2016 by David J Parker

Author:David J Parker [Parker, David J]
Language: eng
Format: mobi
Publisher: Packt Publishing
Published: 2016-05-27T04:00:00+00:00

Once the legend has been dropped onto the page, it can be edited to make the headings and text more readable. In fact, the legend is a special list shape, so through it, each list item could be moved or deleted easily.

Note

Take a look at the following article about the legend with multi-data graphic items: http://blog.bvisual.net/2015/12/24/improving-the-legend-of-multi-data-data-graphic-items-in-visio

Analyzing the composition of a Data Graphic

A Data Graphic is actually stored as a special type of Master in a stencil. The Master contains a reference to each of the graphic items within it along with their configurations. The graphic items are also special masters, except for Color By Value, which is stored as a formula in user-defined cells.

The Data Graphic and Graphic Item masters do not appear in the Document Stencil list, but they are visible in the Drawing Explorer window, as can be seen in the following screenshot:
