Creating the Second Section

Follow these steps: 1.Click 3D Model ➤ Work Features ➤ Plane ➤ Offset from Plane on the ribbon.

2.Select the XZ plane from the Browser window.

3.Enter 8.858 in the Distance box.

4.Click OK .

5.On the ribbon, click 3D Model ➤ Sketch ➤ Start 2D Sketch.

6.Select the newly created datum plane.

7.Right-click and select Center Point Circle from the marking menu.

8.Select the origin point, move the cursor outside, and click to create a circle.
