We will create a program that uses rendezvous to synchronize three loops:

Create the following block diagram. It creates a rendezvous and feeds the reference into three while loops in parallel threads. The case structures in the while loops will execute its false case first, based on the initialized values of the shift registers. The loops will wait for 1, 2, and 3 seconds in parallel. When the wait time is done, the loops will display a string to indicate the status.

The true case is executed after the false case is executed, as shown in the following screenshot. The false case will wait for all the loops using the rendezvous. When all the loops have arrived, a string is outputted to indicate the status.
