Lab 59. Verifying the EIGRP

Database

Lab Objective:

The objective of this lab exercise is for you to learn and understand how to verify the EIGRP database using the appropriate Cisco IOS

commands.

Lab Purpose:

Verifying the EIGRP database is a fundamental skill. EIGRP is an advanced distance vector protocol that incorporates features from both distance vector and link-state routing protocols. The EIGRP

database is a feature of link-state routing protocols. As a Cisco engineer, as well as in the Cisco CCNA exam, you will be expected to know how to verify routes in the EIGRP database.

Lab Topology:

Please use the following topology to complete this lab exercise: Task 1:

Configure hostnames on R1 and R3 as illustrated in the topology.

Since R1 S0/0 is the DCE end of the back-to-back Serial connection, configure R1 to send R3 clocking information at a rate of 256 Kbps.

Configure the IP addresses for R1 and R3 S0/0 interfaces as specified in the topology and ping between the routers to verify connectivity based on your configuration.

Task 2:

Configure the Loopback interfaces on R3 as illustrated in the topology.

Task 3:

Enable EIGRP using ASN 172 on both R1 and R3 and configure EIGRP network statements for R1 and R3 S0/0 interfaces and for the Loopback interfaces on R3. Ensure that EIGRP does not perform automatic summarization at classful network boundaries.

Task 4:

On R1, verify the state of the received routes in the EIGRP database using the appropriate show commands. To take a more detailed look, also verify the EIGRP database information of the 10.20.20.0/24

subnet.
