XBee ZigBee Development Workshop by Agus Kurniawan & Agus Kurniawan

Author:Agus Kurniawan & Agus Kurniawan [Kurniawan, Agus]
Language: eng
Format: azw3
Publisher: PE Press
Published: 2017-07-07T04:00:00+00:00

Change XBee address long value for XBee 1.

The following is a sample output for IS response for remote XBee.

We also can read raw data from serial port. Open remark codes and then try to run.

The following is a sample output on XBee 1.

You can see the data with red underline. The following is data.

7E 00 12 92 00 7D 33 A2 00 41 56 5F 17 00 00 01 01 00 03 00 00 02 A4

Now we can decode these frames based on XBee ZigBee datasheet with API mode = 2. The following is the decoding result of the first frame:

7E. Start transmission

00 14. Frame length

92. frame type (IO Data Sample RX Indicator)

00 7D 33 A2 00 41 56 5F 17. 64-bit remote address

00 00 . 16-bit remote address

01 .Receive option

01 . Number of sampling

00 03 . Digital mask

00 . Analog mask

00 02 . Data value

A4 . Checksum
