effect
Specifies an activity that is executed when a transition happens. This activity can be written using operations, attributes, and links of the owning classifier as well as any parameters of the triggering event. An effect activity may explicitly generate events such as sending signals or invoking operations.
Figure 8-12 shows several transitions between states.
Transition types
UML defines several specific types of transitions . These are described in the following list. There are no special symbols associated with transition types. They are defined only for clarity and common vocabulary.
Compound transition
A representation of the change from one complete state machine configuration to another. Compound transitions are a set of transitions, choices, forks, and joins leading to a set of target states.
