SOLIDWORKS 2016 Learn by doing-Part 1: Parts, Assembly, Drawings, and Sheet metal by Tutorial Books

Author:Tutorial Books
Language: eng
Format: mobi
Published: 2016-02-08T23:00:00+00:00

Click to the create the conic curve. Now, you have to specify the Rho value of the conic curve.

Expand the Parameters section of the PropertyManager, and then type 0.5 in the ρ box.

Click Close Dialog on the PropertyManager.

Move and Rotate Entities

The Move Entities tool moves a selected object(s) from one location to a new location without changing its orientation. To move objects, you must activate this tool and select the objects from the graphics window. After selecting objects, you must define the ‘base point’ and the ‘destination point’.
