Simple SysML for Beginners: Using Sparx Enterprise Architect by Hetherington David

Author:Hetherington, David [Hetherington, David]
Language: eng
Format: epub
Publisher: Asatte Press, Inc
Published: 2019-07-19T00:00:00+00:00

Activities on Activity Diagrams (Non-Standard)

Enterprise Architect supports the use of activities (not just call actions) in activity diagrams. While this feature is not strictly speaking part of the SysML standard, you may find it useful.

Figure 7-55 – Drag activities Returning to our breakfast model, we once again create an activity diagram for the activity “Prepare Breakfast”. We now have two options for using activities directly in this diagram:

We can drag the activity icon from the toolbox to the diagram.

We can drag the subactivities from the project browser to the diagram.
