Practical Arduino Engineering by Harold Timmis

Author:Harold Timmis [Timmis, Harold]
Language: eng
Format: epub, pdf
Tags: Computers, General, Hardware
ISBN: 9781430238850
Publisher: Apress
Published: 2011-10-31T04:00:00+00:00

Figure 6-9. Square cut out of the lid of the enclosure

Put double-sided tape around the square we just cut out.

Take a piece of clear plastic, and cut it to a size that will fit on the hole on the plastic lid (see Figure 6-10).

Figure 6-10. Clear screen attached with double-sided tape

Now that the enclosure has a sunroof, we need to add the small breadboard into the enclosure (see Figure 6-11).

Put the microSD shield on top of the Arduino, and set it inside the enclosure.

Connect the photoresistor to the Arduino, and connect ground to one end of the photoresistor.

Connect the 1kohm resistor to the other end of the photoresistor.
