HDL with Digital Design by Nazeih Botros

Author:Nazeih Botros [Nazeih Botros]
Language: eng
Format: epub, mobi
ISBN: 9781938549816
Publisher: Mercury Learning and Information
Published: 2015-02-09T05:00:00+00:00

pmos p1 (Qbar, s2, D);

pmos p2 (Qbar, s2, E);

pmos p3 (s2, vdd, Q);

pmos p4 (s2, vdd, Ebar);

endmodule

5.6.1.2 Switch-Level Logic Diagram of a D-Latch Using CMOS Switches

Figure 5.22 shows the switch-level logic diagram of the D-latch. When enable (E) is high, CMOS switch c1 is closed, CMOS switch c2 is opened, and Q follows D. When E is low, CMOS switch c1 is opened, CMOS switch c2 is closed, and Q retains its previous value.

Figure 5.22 Switch-level logic diagram of a D-latch using CMOS switches.

Listing 5.19 shows the HDL code for the D-latch. Due to the nature of signal Q, where it is an input and output with more than one source (one CMOS switch and an inverter), Q is declared as inout. Because there are three inverters, the inverter module discussed in Listing 5.3 is bound to the current module D-Latch, rather than writing three individual inverters. In VHDL, use the statement:

for all : invert use entity work.

inverter (Invert_switch);

to bind inverter to the current module D_Latch. In Verilog, we use the statement:

invert inv1 (Ebar, E);

which binds the module invert to the current module D_Latch.
