Generic Electronic circuit Components Projects Hands On: Basic Lie Detector,Short out and Switch Polarity Protection,Solenoid Driver,Piezoelectric Sensor,Square Wave Generator etc.., by K Anbazhagan

Author:K, Anbazhagan [K, Anbazhagan]
Language: eng
Format: epub, mobi
Published: 2020-05-27T16:00:00+00:00

I have utilized a RPS to control the Input voltage, at first the arrangement is tried with 12V and it works fine by turning the bulb on. Later the voltage is raised utilizing the RPS handle accordingly making a short out through the SCR and brushing the circuit which likewise kills the bulb and seclude it structure the force supply.

Confinements of Crowbar Circuit

Despite the fact that the circuit is broadly utilized it comes with its own restrictions which are recorded beneath

The overvoltage estimation of the circuit relies simply on the Zener voltage esteem, and just hardly any estimations of Zener diode are accessible.
