FPGA Prototyping by Systemverilog Examples by Chu Pong P

FPGA Prototyping by Systemverilog Examples by Chu Pong P

Author:Chu, Pong P.
Language: eng
Format: epub
ISBN: 9781119282709
Publisher: Wiley
Published: 2018-05-03T16:00:00+00:00


The address translation circuit decodes the MCS I/O bus’s 32-bit byte address and converts it to the FPro bus’s 21-bit word address and chip-select signals. From MCS processor’s perspective, the FPro I/O system is a single I/O module with a 24-bit byte addressable space (i.e., 22-bit word addressable space) at a base address of 0xc0000000. The address translation circuit decodes the 32-bit address as follows:

bits 31 to 24: used to decode the FPro I/O module base address.

bit 23: used to distinguish the two subsystems and generate the chip-select signals.

bits 22 to 2: used to identify an I/O register or a memory location in the MMIO and video subsystems. They form the 21-bit FPro address.

bits 1 to 0: not used because FPro system uses “word address.”
