Save this program as uart_demo.js file.

4.2.3 Testing

Now you can upload and run program. Read section 2.5 to upload the program.

Now you can see Espruino Pico Terminal shows data which is shown in Figure below.

5. PWM and Analog Input

This chapter explains how to work with Espruino Pico Analog I/O.

5.1 Getting Started

Espruino Pico board provides Analog I/O as PWM and ADC which can be connected to sensor or actuator devices. You can see PWM pins on Cyan color and ADC on Purple color. Note: one pin can be assigned one mode. It means if you assign A5 as ADC then you can use it as PWM.

The following is Espruino Pico layout.

Download
