DO IT YOURSELF GUIDE ON RASPBERRY PI: A complete User Guide to Master Raspberry Pi on your own by Edwards Mike

Author:Edwards, Mike [Edwards, Mike]
Language: eng
Format: epub
Published: 2020-12-25T00:00:00+00:00

Types of GPIOS

For this, we are going to examine two broad types of GPIOs. These would include;

● Integrated Circuit GPIOs; These can be implemented in a variety of ways, such as to provide GPIOs as a primary function or as a somewhat convenient accessory to some other primary function. Guess what, you can carry out multiple activities with your GPIOs, in various ICs. Hence, setting your Pins in a way it would align with your GPIOs becomes expedient; thus, configuration here must influence the behaviors of your Pins and the GPIOs.

● Board-Level GPIOs; Quite a few circuit boards expose these board-level GPIOs to an external circuit by the means of integrated electrical connectors. More often than not, this GPIO is accessed through a special connector pin. Some boards could merely include GPIOs as a convenient or auxiliary resource that could most effectively augment the board’s primary function, comparing other boards where the GPIOs are the central and primary function of the board. The abilities which the IC-based GPIOs usually lack are freely given to the Board-level GPIOs.
