SELECTION OF PANEL

•

Number of modules depends on length and width of both of area and panel.

•

Space between modules between 6 and 10 mm2.

PV type

Efficiency

Space for 1kwh

Monocrystalline

11-16%

6-9 m2

silicon

Polycrystalline

10-15%

7-10 m2

silicon

Thin film

6-11%

9-17 m2

Hybrid silicon

16-18%

5-6 m2

Micromorphous

7-12%

8.5-15 m2

Amorphous

4-7%

15-26 m2

DATASHEET OF PANEL

INVERTER SELECTION

To select inverter, sum all of the loads in kw and choose higher value for inverter.

If total load= 3.9 kw, then we choose inverter of 4 kw.

Type

Power in Kw

Efficiency
